Hot Sale China Sheet Metal Cnc Fiber Laser Cutting Machine with Exchange Table from Dongguan TAIYI Laser
Advantage of SS Plate CNC Laser Cutting Enquipment
1) Excellent beam quality: Smaller focus diameter and high work efficiency, high quality.
2) High cutting speed: Cutting speed is more than 60m/min
3) Stable running: Adopting the top world import fiber lasers, stable performance, key parts can
reach 100,000 hours;
4) High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine,
fiber laser cutting machine has three times photoelectric conversion efficiency
5) Low cost & Low maintenance: Save energy and protect environment. Photoelectric conversion rate
is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser
cutting machine. Fiber line transmission no need reflect lens, save maintenance cost;
6) Easy operation: fiber line transmission, no adjustment of optical path;
7) Super flexible optical effects: Compact design, easy to flexible manufacturing requirements.
Feature & Property of SS Plate CNC Laser Cutting Enquipment :
1.The machine enjoys a good performance with high cutting speed, high efficiency, safety and stability.
2.The laser spot enjoys good quality. And the machine distorts just slightly. Besides, the material can have a smooth and nice appearance.
3. After tempering treatment, the frame with high rigidity is of high vibration-absorbed performance. The frame with gantry structure is one-step processed in large CNC gantry machining center. With optimized structure, the machine enjoys stability and high accuracy which can be controlled within 0.01mm/m.
4. Imported servo motor, planetary reducer, and sophisticated direction drive mechanism ensure steadiness and accuracy.
5. Intuitive HMI with many practical functions is easy to operate.
6. Imported bevel gear, helical rack, linear guide rail ensure highly precise running direction.
7.The auto-height & anti-collision system automatically adjusts the hermetic cutting head at the proper height to cut at a fixed distance.
8.The power supply of the machine is designed with automatic safety protection, and features fault alarm.
Cutting materials of SS Plate CNC Laser Cutting Enquipment
The fiber laser can cut all kinds of non ferrous metals, such as copper,aluminum,this high reflective materials, and tungsten,can also cut stainless steel,carbon steel, manganese steel,galvanized sheet,aluminum platform gold alloy plate, and other rare metals.
Application industry of SS Plate CNC Laser Cutting Enquipment
The fiber laser cutting machine can be widely used in aerospace, aviation, electronics, elevators, medical equipment, kitchen electrical, auto parts, electrical equipment, gold plated chassis cabinets,mechanical equipment,lighting hardware,advertising signs, display equipment,all kinds of metal products, sheet metal cutting processing and other industries.
CNC Laser Cutting Machine Models
Hot Sale China Sheet Metal Cnc Fiber Laser Cutting Machine with Exchange Table from Dongguan TAIYI Laser
Model | TY-3015DJ |
Laser source medium | Fiber |
Cutting range (L * W) | 3000 mm × 15000 mm |
Z axle stroke | 250 mm |
Max. positioning speed | 120 m/min |
X,Y axle Max. accelerate speed | 1.0G |
Cooling form | Water cooling |
Laser wavelength | 1070nm |
Output power of laser source | 500W/1000W / 1500W / 2000W 2500W / 3000W / 4000W (Optional) |
Min. cutting gap | ≤ 0.1 mm |
Positioning accuracy of X, Y and Z axles | ± 0.03 mm |
Repeated positioning accuracy of X, Y and Z axles | ± 0.01 mm |
Thickness of cutting material (according to material) | 0.2 - 25 mm |
Driver model | Imported servo motor |
Power requirement | 380V, 50/60 Hz |
Working temperature | 0-45℃ |
Continuous working time | 24 Hours |
Machine weight | About 4600Kgs |
Total protection level of power supply | IP54 |
Laser Power | Max cutting thickness | |||
Carbon steel(mm) | Stainless steel(mm) | Aluminum (mm) | Brass (mm) | |
800W | 8 | 3 | 1 | 1 |
1000W | 12 | 4 | 2 | 2.5 |
1500W | 14 | 5 | 4 | 3 |
2000W | 16 | 6 | 5 | 4 |
3000W | 22 | 10 | 6 | 8 |
Above parameter for reference only |
| Name:Machine body and accessories a.600℃ heat treatment, 24 hours cooling in the oven, accurate CO2 protection welding, to make sure 20 years usage without deformation. |
Name:AC servo motor & driver The imported servo motor (Y-axis driven by two servo motors) along with the sophisticated planetary reducer ensures steady, precise and reliable drive. |
|
Name:Precision Linear Guides Advanced cutting system, laser power and servo movement suit each other perfectly, imported high precision gear and rack drive system, exchangeable double work table, to ensure higher processing speed and accuracy.. | |
Name:Cutting head The contactless cutting head has the function of auto height tracking and anti-collision, which greatly improves cutting speed, smoothness and cutting accuracy under the same output power. In a word, the cutting efficiency can be increased. | |
Name:Laser source fast speed,high precision cutting line, and smooth cutting edge |
After signing the contract , your company can arrange technologist come our factory to learn basic knowledge of equipment and operating essentials , sufficient training time about 1-3 days , the training content is as follows:
a) Common drawing software training ;
b) Machine on and off training procedures ;
c) The significance of control panel and software parameters, parameters range’s setting;
d) Basic cleaning and maintenance of the machine ;
e) Common Hardware Troubleshooting ;
f) Caution of operation,
a).2 Year for the whole machine(Man-made Damage is negotiated.).
b).Laser source 2 Year warranty
c).Lifelong maintenance and spare parts supply
d).Free training for operation staffs. (engineer can go abroad is negotiated.)
