Product Name | China 1Kw 4Kw 5Kw 500W 1000W 500W cnc cutter 3d Sheet Tube Iron Stainless Steel Aluminum Metal Fiber Laser Cutting Machine Price |
Power | 500w/600w/1kW/2kw/3kw/4kw/5kw/6kw |
Cutting area(L*W) | 3000mm*1500mm/4000*2000mm/6000*2000mm |
Cutting thickness | 0.2mm-12mm |
Total electric power consumed | 10kw/h |
Laser Cutter Cutting speed | According to the thickness |
CNC system | Germany Reckhoff or customized |
Laser | RAYCUS/ipg |
Reducer | Germany Newcut |
Rack and pinion | Taiwan YYC/APEX |
Linear Guides | Taiwan PMI |
Cooling system | Water cooling |
Laser Cutting head | RAYTOOLS |
Appliances | France Schneider |
Servo motor | YASKAWA |
Laser power option
IPG: 500w,750w, 1000w, 1500w, 2000w, 3000w, 4000w, 6000w, 8000w,10000W, 12000W
Raycus: 500 watt, 750 watt, 1kw, 1500W, 2kw, 3kw, 4kw, 5kw, 6kw, 8kw, 10kw
MAX: 500 watt, 750 watt, 1000 watt, 1500 watt, 2000 watt, 3000 watt, 4000 watt
Machine size:3015, 3020, 4015, 4020, 6015, 6020, 1025, customized size available.
Table type: Single table, auto feeding shuttle table,
Enclosed table, open table all available,
Plate and tube cutting table, tube cutting machine available.
Main features of laser cutting machine
(1).It is for metal precise cutting powered by fiber laser technology.
(2).Excellent beam quality. The quality fiber laser beam results in faster cutting speeds, higher quality cuts compared to other
cutting solutions.
(3).The key advantage of a fiber laser is its short beam wavelength . The wavelength, which is ten
times lower than that of C02 laser, generates high absorption into metals.makes it become a perfect
tool for cutting metal sheets of stainless steel, carbon steel, mild steel, aluminum, brass, etc.
4) Extremely high cutting speed:under the same power,the cutting speed of fiber laser cutter is twice CO2 laser cutting machine.
5) High stability: adopts the world's top imported fiber laser, stable performance, key components life is up to 100 thousand hours;
6) High electro-optical conversion efficiency: the electrical to optical conversion efficiency of fiber laser cutting machine than CO2 laser cutting is three times higher, energy-saving environmental protection.
7) Extremely low cost of use: the power consumption of the whole machine is only 20-30% of the same kind of CO2 laser cutting machine;
Applicated material:
Most metal materials such as carbon steel, stainless steel, alloy steel, copper, brass, steel, galvanized steel, nickel titanium alloy, nickel chromium alloy and titanium alloy, etc..
Applicated industries:
Sheet metal cutting, locomotive manufacturing, electrical switch manufacturing, aerospace, food machinery, textile machinery,
engineering machinery, agriculture and forestry machinery, elevator, vehicles, household appliances, tools, processing, IT manufacturing, oil
machinery, food machinery, diamond tools, welding, welding gear, metal materials, decoration
advertising, laser surface treatment of foreign processing services, such as all kinds of machinery
processing industry.
Contact us for clear specifications with a clear offer of this product.
Q:How can I choose suitable machine?
A:Please kindy send an inquiry and tell us your material size and thickness. We will advize accordingly.
Q:MOQ?
A:No MOQ limit. If you purchase large quantity, we will be happy to offer big discount.
Q:If I purchase a machine, how can you make it safe while shipping?
A:For fiber laser cutting machine, we can load container in our factory directly.
Q:Can you do OEM?
A:Yes, we can provide OEM service.
