BCC YAG 5050 Laser Cutting Machine
BCC SERIES YAG laser cutting machine adopts the most sophisticated Germany YAG laser source as the Power source ,equip 2D worktable with Servo Motor .
Working principle
Cutting is achieved by powerful laser focused on object to cause instant melting and evaporation, with xenon lamp as the generator . Automatic cutting is controlled by digitalized mechanic system .This machine has condensed the technologies of laser, digital,and precise mechanics.
Advantage
1:Smooth and fine edge or surface and small distortion. Higher cutting speed and low cost, operation safe and stable function. Imported servo motor and gearing system to guarantee precise cutting.
2:Dedicated software enables graphic or text to be instantly designed or processed .Flexible and easy operation.
3:Automatic Focusing System
Application Fields
Applicable to cutting on plate or tube in metal or non-metal materials.Idea for cutting on S/S, carbon steel ,alloy steel, copper plate, aluminum, rare metal, porcelain chip, silicon chip, diamond. widely used in sheet metal processing, metalware, kitchen appliance. high-resolute device, electric control box,auto parts,glasses,posters,crafts,lighting,and precise parts.
Technical Parameters
Model | BCC SEIRES |
Laser Type | Imported Original Fiber Laser |
Laser Wavelength | 1064nm |
Laser Maximum Power | 500W | 600W | | | |
Max. Cutting thickness | ≤8mm | ≤10mm | | | |
Total Power Consumption | <18KW | <20KW | | | |
Working Size | 300x300mm/500x500mm/600x600mm/800x800mm |
Max.cutting speed | 0-20m/min(Depending on the material and thickness) |
X, Y, Z Axis Orientation Precision | ≤±0.08mm/m |
X, Y, Z Axis Repeat Precision | ≤±0.05mm /m |
Min line width | ≤0.15mm |
Maximum Empty Running Speed | 80m/min |
Driving way | Imported servo motor |
Tranmission way | Y-axis importe gear rack double driver,X-axis imported ball screw |
Worktable Max Load | 1600 KGS |
Cooling System | Water Cooling |
Continous working time | 24 Hours |
Environment temperature | 0-35°C |
Power requirements | 380V/3 Phases /50Hz or 60Hz |
