Advantages 1. Permanent Laser marking is permanent and indelible marking process, which stands against wiping, scuffing, impacts, wear and tear, can only be removed by grinding or surface removal. Thus laser marking sustains authenticity of your brand against sort of tempering. 2. Non-contact Laser marking is non-contact type process. It does not produce any deformation in producing, unlike in punching, stamping, pneumatic pin, vibratory pencil, etc. This gives accurate and aesthetic marking independent of hardness material. 3. Flexibility Laser marking is highly flexible process compare to any other marking process. It can mark any images and fonts without changing any punch, die, stencil, etc. Unlike other conventional process. 4. Aesthetic / Accuracy Since laser can produce very fine beam with accuracy in micron, many accurate and micro details with precision can be marked with laser marking. Laser can produce aesthetic images which other machine difficult to create. 5. No pre or post processing Since laser marking is non-contact type, no pre or post processing is required, which in turn significantly increase marking productivity. 6. Low operating cost Laser marking helps siginificantly in marking operationg cost by reducing labor cost, tool cost, consumable costs, set up time, rejection improved cycle time. 7. Automation One of the prime advantage of laser marking is that it can be automized and can be integrated with any online process. |
Features 1. High quality laser beam for fine marking-----Min. laser line width can reach 0.02mm. 2. High makring precision and speed. 3. Low consumption, energy saving-----about 0.5kw for whole machine. 4. Advanced air-cooling system. | ||
Technical Specifications | ||
Model No. | HLF10 | HLF20 |
Laser Power | 10W | 20W |
Laser Type | Fiber Laser | |
Laser Wavelength | 1.00-1.10um | |
Modulation Frequency | 20-100KHZ | |
Max. Marking Speed | 7000mm/s | |
Marking Area | 70mm/110mm/220mm | |
Repeated Accuracy | 0.01mm | |
Position Accuracy | 0.01mm | |
Marking Depth | 0.01-0.3mm | |
Spot Diameter | 10um | |
Cooling System | Air Cooling | |
Voltage | AC220V±10%; 50Hz | |
Applicable Materials Applies to all metal, PVC materials. Application Area The device is widely used in electronic components, communications equipment, automobile and motorcycle parts, instrumentation, military products, mechanical hardware, measuring and tools, etc. |
Fiber Laser Marking Sample
