Product Features:
1. Laser tube: 60w, 80w, 100w, 150w and 180w
2. Software: lasercut, support output from Corel Draw, AutoCAD directly.
3. Honeycomb table for fabric, leather, engraving, cutting Aluminum blade-piece table for acrylic, wood cutting.
Applicable materials:
Wood, bamboo, jade, marble, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials.
Applicable industries:
Advertisement, arts and crafts, leather, toys, garments, model, building upholster, computerized embroidery and clipping, packaging and paper industry.
Specifications of laser foam cutting machine and 3d laser engraving machine price :
Product model | sk1290 | |||
Engraving Area | 1200×900mm | |||
Laser tube | 80W(optional 60w, 100w, 150w) | |||
Laser Type | CO2 Laser Tube | |||
Engraving speed | 0~1200mm/s | |||
Cutting speed | 0~600mm/s | |||
Resetting positioning accuracy | <0.01mm | |||
Cutting depth | Acryl 0-10mm(other depths depend on other materials) | |||
Minimum Shaping Character | 1×1mm | |||
Power supply | 220V±10% 50HZ or 110V±10% 60HZ | |||
Gross power | 1200W | |||
Software supported | ArtCut, CorelDraw, PhotoShop, AutoCAD | |||
Graphic format supported | PLT,DXF,BMP,JPG,GIF,PGN,TIF | |||
Engraver for Curve surfaces (Yes/No) | No (we can add an Rotary attachment on the Laser Engrave/Cutting Machine, then the machine can engrave on Cylinder) | |||
Water Cooling: (Yes / No) | Yes | |||
Maximum Height of Materials to Engrave (mm) | 280mm(Up and down by motor) | |||
Laser Tube (life hours) | 3000 hours | |||
Assistant Equipment | Water pump | Exhaust Fan | Aluminum alloy worktable | |
Optional Spare Parts | RF Tube | Rotary System | Cooling water system | Red dot point |
Recommended Spare Parts / Consumables | Laser Tube and Lens |
detail pictures of the laser cutting machine of laser foam cutting machine and 3d laser engraving machine price :
Certificate CE & FDA
|
Machine packing
Our factory and customers After sale service
Please let me know such information
1.What kind of material do you want to process?
|
CE& FDA certificate
Warranty terms:
1. 1 year for the whole laser cutting machine.
2. 10 months for Reci laser tube, 3 months for ordinary CO2 laser tube.
3. 6 months for assistant parts, such as water pump (chiller) , exhaust fan, air pump, etc
4. 3 months for mirrors & lens
Contact information
Contact person :Echo
Skype :sukelaser3
Big Size 180W CO2 Laser Cutting Mesin Fabric Leather Machine Price
1). Adopts quality & steady co2 sealed laser tube --80W, 100W, 130W, 150W & 180W
2). X.Y axis adopts Taiwan imported Hiwin Linear guide rail & Belt, make sure the working accuracy.
3). Special researched 2 Parallel exhaust path, and equip 2PCs 750W big power exhaust fan,
guarrantee the smoke can be taken out even with thick wood cutting.
4). Honeycomb work table for cloth, leather and textile cutting,
blade piece work table for wood , mdf, acrylic cutting
5). DSP offline RD6442G controller and RD WORKS V8 software--easily use and human interface
6). Auto sensor laser head for metal cutting--maxi cut steel 2mm thickness
