CM-1390 New Style Wood Acrylic Foam Plastic CO2 Laser Cutting Machine Price
Standard Features For Laser Cutting Machine:
1. CO2 Sealed glass Reci laser tube.
2.Stepper Motor Module Combination,when this machine move in very high speed, it can make the machine stable, don't shake,so the engraving and cutting precision is very high, the cut surface of acrylic almost no flow mark.
3.The laser path is very stable, once you fix it well, the laser path can keep stable for very long time, so the user don't need adjust the laser path usually.
4. DSP controlling system, rich functions, can effect engraving on plane, gradient engraving by 360 degree,
cutting and drilling holes etc.It can completely work off-line and do not take any computer resources
5. Has the function of re-carving after break point and power failure.
6. Transmit files directly in Coreldraw, AutoCAD,etc.
7. Adopt High Speed guide rails, move very fast
8.Water chiller cooling system, can cool the laser tube well.
9. Has the function of forecasting process time.
10. Sub-divistion stepper motors
Applicable Industries For Laser Cutting Machine:
Model Industry(construction models, aviation and navigation models and wooden toys), advertising, decoration, art crafts, and electric appliances, etc.
Applicable Materials For Laser Cutting Machine:
Non-metal materials such as acrylic, wood planks(light planks), bamboo ware. Double colored boards, paper, leather, shells, coconut shells, ox horns, resin animal grease,ABS boards, etc.
Model For Laser Cutting Machine | CM-1390 |
Laser Power | 90W Reci Brand |
Laser Type | CO2 sealed, glass laser tube, water cooling |
Work Area | 1300 X 900 mm |
Cooling Type | Water-cooled and Protection System |
Engraving Scanning Speed | 0-60000 mm/min |
Cutting Speed | 0-1000mm/min |
Laser Output Control | 1-100% Software Setting |
Smallest Character Engraving | English: 1.0X1.0 mm |
Highest Scanning Precision | 2500DPI |
Power Supply | AC 110-220V±10%, 50-60Hz |
Operating Temperature | 0°-45°C |
Operating Humidity | 5%-95% |
Locating Precision | ≤±0.01mm |
Supported File Format | DST,PLT,BMP,DXF,AI |
Compatible Software | TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,All Type of AUTOCAD Software in cloth |
Driving System | Stepper Electrical Motor |
Package Dimension | 1800X1400X1300 mm |
Net Weight | 350 KGS |
Gross Weight | 400 KGS |
Optional Spare Parts | Up-down Worktable, Rotary System, Honeycomb Worktable |
Removable Spare Parts | Laser Tube and Lens |
CO2 different power cut thickness on different materials
Materials | 40W | 50W | 60W | 80W | 100W | 150W | 200W | 360W |
Wood | 3mm | 4mm | 5mm | 10mm | 12mm | 15mm | 18mm | 20mm |
Plywood | \ | 4mm | 5mm | 10mm | 12mm | 15mm | 18mm | 20mm |
Glass | \ | \ | \ | \ | \ | \ | \ | \ |
Leather | 1mm | 1.5mm | 2mm | 3mm | 4mm | 5mm | 8mm | 8mm |
Acrylic | 3mm | 8mm | 10mm | 15mm | 20mm | 20mm | 25mm | 30mm |
PVC | 1mm | 2mm | 3mm | 4mm | 5mm | 6mm | 8mm | 10mm |
Plexiglass | 3mm | 5mm | 6mm | 8mm | 10mm | 12mm | 15mm | 20mm |
Plastic | \ | 1.5mm | 2mm | 3mm | 4mm | 5mm | 6mm | 10mm |
Rubber | \ | 2mm | 3mm | 4mm | 5mm | 6mm | 8mm | 10mm |
Crystal | \ | \ | \ | \ | \ | \ | \ | \ |
Jade | \ | \ | \ | \ | \ | \ | \ | \ |
Stone | \ | \ | \ | \ | \ | \ | \ | \ |
Polymethyl Methacrylate Plastics | \ | 8mm | 10mm | 15mm | 20mm | 20mm | 25mm | 30mm |
Marble | \ | \ | \ | \ | \ | \ | \ | \ |
medal | \ | \ | \ | \ | \ | \ | 1.5mm | 2mm |
Clothing | 0.5-3mm (fabric/wool) | |||||||
Bamboo Works | \ | 3mm | 3mm | 4mm | 5mm | 6mm | 8mm | 10mm |
Paper | 0.5-3-5mm | |||||||
Above sheet only for reference,because in different country same materials different components |
CO2 laser cut machine engrave cut on different materials
item | Materials | Engrave | Cut |
1 | wood | √ | √ |
2 | Acrylic | Yes | Yes |
3 | Fabric | Yes | Yes |
4 | Glass | Yes | No |
5 | Coated Metals | Yes | No |
6 | Ceramic | Yes | No |
7 | Delrin | Yes | Yes |
8 | Cloth | Yes | Yes |
9 | Leather | Yes | Yes |
10 | Marble | Yes | No |
11 | Matte Board | Yes | Yes |
12 | Melamine | Yes | Yes |
13 | Paper | Yes | Yes |
14 | Mylar | Yes | Yes |
15 | Pressboard | Yes | Yes |
16 | Rubber | Yes | Yes |
17 | Wood Veneer | Yes | Yes |
18 | Fiberglass | Yes | Yes |
19 | Painted Metals | Yes | No |
20 | Tile | Yes | No |
21 | Plastic | Yes | Yes |
22 | Cork | Yes | Yes |
23 | Corian | Yes | Yes |
24 | Anodized Aluminum | Yes | No |
25 | Stainless Steel | yes | yes |
26 | Brass | No | No |
27 | Titanium | No | No |
28 | Bare Metals | No | No |
