Polyester/PVC Fabric Laser Cutting Machine for Tent,Marquee,Awning
Features:
- Highest quality laser motion control system
- 32DSP control technology achieving fast continuous curve cutting
-complete exhaust and flitering of cutting emissions
-secured and intuitive control of the system with software-independent.
-smooth and flat cut cross secion
-optinal device:CCD camera red light position system ,up and down working table,auto feeding system.
Technical Parametershua
Model of Machine | HL9060D | HL10060 | HL12060 | HL13090 | HL160100 | HL180100 |
Laser tube | CO2 LASER | |||||
Cutting Area | 900*600mm | 1000*600mm | 1200*600mm | 1300*900mm | 1600*1000mm | 1800*1000mm |
Laser Power | 60w-150w | |||||
Cutting Speed | 10m/min | |||||
Engraving Speed | 0-1200mm/s | |||||
Location Precision | <0.02mm | |||||
Weight | 300kg | |||||
Working environment | Temperature: 0-40°, Humidity: 45%-85% | |||||
Marking depth | 0-0.3mm | |||||
Min. line width | 0.02mm | |||||
Min. character | 0.2mm | |||||
Graphic Format | BMP, HPGL(PLT), JPEG, GIF, TIFF, PCX, TAG, CDR, DWG, DXF, compatible HPG order, support DXF, PLT, BMP and DXT(Tiandao embroider software), etc. | |||||
Auxiliary device | exhaust fan and cooling system |
Special for fabric feeding unit
The feeding unit is a optional feature for the conveyor,allowing further abtomation of textile and foil laser processing .the materias is forwarded from the coil to the laser system where it is cut or engraved.
The automatic edge control of the feeding unit ensures a constant alignment and thus continuously precise high quality cuts meter by meter
Advantages
1).Visible Red Dot Pointer
Make the laser beam "visible"
2).Emergency stop
Turn off the machine immediately when there is an accident
(3).Motorized table
Control the table up/down from LCD panel directly
4).Open flap protection
Laser will stop working if you open the front cover
5).Mirror mount
Easily re-adjusting mirror mounts
6).LCD panel
Set speed, power, and more directly from the LCD panel.
7).Color mapping
Change the working speeds and power by using color settings.
8).Water protection
Laser will stop working if the water cooling system is not working
9).High quality rails
Keep the engraving/cutting precise and very durable
10).Honey comb table
Allows the laser beam to pass through the material you are cutting and reduces underside reflections.
Also other table, such as knife strip available!
11) Auto focus
Help the user to set the focus Easier. (based on motorized table)
