Made in Guangzhou 20 w fiber laser marking machine Hardware plastic laser laser engraving machine
Free sample printing service is offered.
1.Introduction
Our fiber laser marking machine outputs laser through fiber laser device, it has high electro- optical conversion rate, small size, good beam quality and does not require any water cooling system. Fiber laser device is the world’ s most advanced, whose service life is long and maintenance charge is low. With superior technical accessories, the fiber laser marking machine has fast speed and stable performance and has won the trust of many customers for its excellent performance and reliable quality.
2.Configuration
Name | Brief description |
Laser device | Solid fiber laser device |
Focusing system | Three red light auto focusing system |
Marking indicating system | Built- in indications of outline, size and direction |
Lens system | Import wavelength, the whole series of lens |
Cooling system | Air cooling |
Laser vibration lens | Integrated optical bench design, professional digital galvanometer, high speed vibrating lens |
Professional laser control card | Professional static marking software |
Computer and marking software | Industrial design computer, 18.5″ large screen LCD |
bracket | Lifting 500mm |
Features and Advantages:
1. The high quality laser
2. The wavelength of 1064 nm high-energy laser pulse output
3. Good laser beam mode, electro-optic conversion efficiency is high
4. The whole machine low energy consumption, maintenance free
5. The machine has compact structure, small volume
6. The machine running in stability, high safety
7. The whole machine, simple and convenient operation, high precision marking quality
8. The software intelligent control part design, the menu is with user friendly interface
9. Provide a variety of data interface hardware control part, automated actions
10 it meets the demands of industrial field work continuously for a long time
11. Marking software powerful: support Coreldraw, AutoCAD, Photoshop software,
Support the PLT, DXF, BMP, PCX, JPG and other commonly used vector graphics and bitmap graphics.
Support to print date, serial number, bar code, the qr code, automatic coding and automatic number, etc
3.Technical Parameters
power | 10W/20w/30w/50w |
Laser wavelength | 1050-1070nm |
Repetition frequency | 20-30KHZ |
TEMOO Gaussian beam | <2 |
Marking range | 100*100mm 200*200mm 300*300mm,500*500mm(optional) |
Marking depth | ≤0.4mm |
Marking speed | ≤10000mm/s |
Minimum linewidth | 0.01mm |
Minimum character | 0.15mm |
Repeat accuracy | ±0.002 |
Power supply | 220V/50Hz |
Power consumption | 500W |
dimension | 570mmX270mmX200mm |
Total weight | About 90kg |
Operating system | WinXP |
cooling | Built- in air cooling |
control interface | Standard USB |
File format | All the characters/ fonts of WINDOWS operating system |
Laser device type | Impulse fiber laser device |
4. Application
Our fiber laser marking machine is mainly applied on metals and some non- metals, especially designed for the industrials have high requirements in depth, smoothness and fineness, such as sanitary ware, medical appliance, glasses, clocks, watches, automobile fittings, plastics, paper, electronic hardware.
Our product contains: Small Character Ink Jet Printer, High Resolution Ink Jet Printer, Handheld Inkjet Printer, Big Character Ink Jet Printer, Laser Marking Machine, Vocuum Packing Machine, Carton Sealer, Shrink Packing Machine, Wrap Packing Machine, Strapping Machine, Automotic Labelling Machine and etc.
Welcome to contact us for more information.
-------------------------------------------------------------
Guangzhou Dafeng Machinery Equipment Co.,Ltd
TEL:+86-20-62911616
Mobile/whats app:+86-186-6662-0535
Email: tsunny2000*hotmail.com
Contact: Sunny Tang
