Laser Cleaning Machine External Cleaning of Large Diameter Pipes
|
Type |
LXC 500W |
|
Laser source |
JPT |
|
Pulse Formation |
Q-Switched (Quality factor) |
|
Average Power (W), Max |
500.00 |
|
Output power instability |
＜3% |
|
Center wavelength (nm) |
1064 |
|
Pulse-Frequency (KHz),Range |
20-50 |
|
Scanning Width (mm) |
10~140mm |
|
Expected Focal Distance(mm) |
160mm/210mm |
|
Storage temperature (℃) |
-20~60 |
|
Cooling Type |
Water cooling |
|
Cleaning efficiency (m2/h） |
50 |
|
Input Power |
Single-phase 220V±10%, 50/60Hz AC |
|
Power Consumption (W) |
4000W （including Chiller） |
laser gun
- Wireless module, easy to operate
- 140mm scan width, high working efficiency
- Consumables easily change
control system
- LED touch screen, easy to operate
- Recommend parameters, easy to set
- Language customized
Water chiller
- China high quality brand
- Stable cooling ability
- Low failure rate
JPT laser source
- China famous laser source brand
- Stable quality
Hiwin rails
- The rolling guide wear is very small,can maintain accuracy for a long time.
- The friction is very small,the power loss is small;the heat generated during operation is extremely small,and it can run at high speed.
Support frame
- It can support the pipe to move and turn
After Service
1.The warranty of machine is 2 years(excluding consumables and man-made damage), laser source is subject to the suppliers’ policy. The time is from the point when sales inform customer machine is ready.
2.Lifetime maintenance free of charge.
3.Free training course at our plant.
4.Specialized after-sales service group 18 hours online each day, to provide free technical support by email, whatsapp, wechat and so on.
5.Machine has been tested and adjusted before delivery, you can use the machine directly after receiving it.
