Laser Power:1000-2000W
Laser Wavelength:1070nm
Pluse Frequency:1-500Hz(adjustable)
Auto Wire Feeder:Including
Cooling Type:Water Chiller
Operate Mode:Continuation/Modulate
Spot Adjusting Range:0.1-3mm
Repeating Precision:±0.01mm
Voltage:220V,1PH/380V,3PH
Features
1.The energy density is high, the heat input is low, the amount of thermal deformation is small, and the melting zone and the heat-affected zone are narrow and deep.
2.High cooling rate, which can weld fine weld structure and good joint performance.
3.Compared with contact welding, laser welding eliminates the need for electrodes, reducing daily maintenance costs and greatly increasing work efficiency.
4.The weld seam is thin, the penetration depth is large, the taper is small, the precision is high, the appearance is smooth, flat and beautiful.
5.No consumables, small size, flexible processing, low operating and maintenance costs.
Application
This machine is suitable for welding of gold, silver, titanium, nickel, tin, copper, aluminum and other metal and its alloy material, can achieve the same precision welding between metal and dissimilar metals, has been widely used in aerospace equipment, shipbuilding, instrumentation, mechanical and electrical products, automotive and other industries.
After-sale Service
● # 24 months guarantee of the whole machine, we will provide the consumable parts at an agency price when you need replacement.
● # Main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
● # English manual and CD video for machine using and maintaining will send to you with the machine.
● # Our engineer can offer technical support in your country if necessary,or get train in our factory for free.
● # 7*24h online technical support .
Product Parameter
Model | LXW-1000/1500/2000W |
Laser power | 1000/1500/2000W |
Center wavelength | 1070+-5nm |
Laser frequency | 50Hz-5KHz |
Work patterns | Continuous |
Electricity demand | AC220V |
Output fiber length | 5/10/15m (Optional) |
Cooling method | Water Cooling |
Dimensions | 1150*760*1370mm |
Weight | 275kg(About) |
Cooling water temperature | 5-45℃ |
Average consumed power | 2500/2800/3500/4000W |
Laser Energy Stability | <2% |
Air humidity | 10-90% |
COMPANY PROFILE
Jinan Lingxiu Laser
Is established in July 2004 owns more than 500 square meters of researching and office space, more than 32000 square meters factory All machines, passed the European Union CE authentication American FDA cerificate and are certied to ISO 9001. Products are sold to USA, Canada, Australia, Europe. South east Asia, Afica etc, more than 120 counties and areas, and supply OEM service for more than 30 manufactures.
Our Products includes All kind of
1. Laser welding machine.
2. Laser marking machine (Fiber / CO2/UV / Green light).
3. CNC knife cutting machine.
We can also customized non-standard assist equipment as your detailed work reauirements.
