    APPLICATION

    Application Materials:

    Fiber Laser Cutting Equipment is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc

    Application Industries:

    Soullon Fiber Laser Cutting Machines are widely used in manufacture Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc.

    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 11
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 12
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 13
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 14
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 15

    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 16 CHARACTURE Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 17

    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 18
    High rigidity heavy chassis, reducing the vibration generated during the high-speed cutting process.
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 19
    Gantry double-drive structure,with imported Germany rack & gear transmission system, which improves the production efficiency.
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 20
    High-performance cast aluminium guide rail, after infinite aalysis ,which accelerates the cicular arc cutting speed.
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 21
    Open worktable, easy operation and small space occupation.
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 22
    High precision, fast speed, narrow slit, minimum heat affected zone, smooth cut surface and no burr.
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 23
    The laser cutting head does not come into contact with the surface of the material and does not scratch the workpiece.
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 24
    The slit is the narrowest, the heat affected zone is the smallest, the local deformation of the workpiece is very small, and there is no mechanical deformation.
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 25
    It has good processing flexibility, can process any pattern, and can cut pipes and other profiles.
    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 26
    Non-deformable cutting can be performed on materials of any hardness such as steel plates, stainless steel, aluminum alloy plates, and hard alloys.

    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 27 PRODUCT PARAMETER Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 28

    Machine Name

    1500W 2200W 3300W

    High Power Metal Plate Fiber Laser cutting machine with exchange table LXF3015J

    Model

    LXF3015R

    Laser machine cutting area

    3000x1500mm

    (Other size can be customized,such as 4500x1500/6000x1500/6000x2000mm)

    Tube Cutting Range

    Tube diameter range:20-200mm

    Tube length:6000mm

    (Other size can be customized,detailed confirmed with sales)

    Fiber Laser Power

    CO2 Laser Power

    500w/750w/1000/1500/2200/3300/4000/

    6000/8000/12000/25000W

    Laser wave length

    1064nm

    Transmission system

    Gear + rails
    (we have standard brand,we can also produce as your requirements)

    X.Y axis location accuracy

    ±0.01mm

    X.Y axis repeat location accuracy

    ±0.01mm

    X.Y axis max moving speed

    30m/min

    Max cutting speed

    1--30m/min(it will according to metal material and laser power)

    Cutting thickness

    Detailed in the following cutting thickness

    Application Material

    Metal sheet
    Iron/CS/SS/Aluminum/Copper and all kinds metal

    Advantages

    >Excellent beam quality
    >Simple , compact, electrically and optically efficient
    >Compatibly powerful and reliable
    >Maintenance free
    >Multilingual, more than 11 foreign languages
    >3 years warranty .

    Gross weight

    6500KG(About)

    Net weight

    6250KG(About)

    Machine size

    Rotary size:8000*1600*1150mm

    Machine size(without rotary):

    4160*2200*1980mm

    Detailed machine size will be according to detailed configuration.this size for your reference.

    Transport 40 container + 20 container

    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 29 PRODUCT SELECTION Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 30


    Material

    Thickness

    mm

    500W

    1000W

    1500W

    2000W

    3000W

    4000W

    6000W

    8000W

    10000W

    12000W

    Cutting   Speed(m/min)

    Carbon Steel

    (O2)

    1

    7.0~8.0

    7.0~9.0

    7.0~11.0

    7.0~12.0

    7.0~12.0

    7.0~12.0

    7.0~12.0

    7.0~12.0

    7.0~12.0

    7.0~12.0

    2

    4.0~5.0

    5.0~6.0

    5.0~6.5

    5.0~6.5

    5.0~7.0

    5.0~7.0

    5.0~7.0

    5.0~7.0

    5.0~7.0

    5.0~7.0

    3

    2.0~2.5

    2.5~3.0

    2.8~3.8

    3.0~4.6

    3.5~5.0

    3.5~5.0

    3.5~5.0

    3.5~5.0

    3.5~5.0

    3.5~5.0

    4

    1.5~2.0

    2.0~2.4

    2.5~3.2

    2.8~4.0

    3.0~4.2

    3.0~4.2

    3.0~4.2

    3.0~4.2

    3.0~4.2

    3.0~4.2

    5

    1.2~1.5

    1.5~1.8

    1.8~2.5

    2.2~3.2

    2.5~3.6

    2.5~3.6

    2.5~3.6

    2.5~3.6

    2.5~3.6

    2.5~3.6

    6

    1.0~1.4

    1.4~1.6

    1.6~2.2

    2.0~2.8

    2.4~3.0

    2.4~3.0

    2.4~3.0

    2.4~3.0

    2.4~3.0

    2.4~3.0

    8


    1.0~1.2

    1.1~1.5

    1.4~2.0

    1.8~2.4

    1.8~2.4

    1.8~2.4

    1.8~2.4

    1.8~2.4

    1.8~2.4

    10


    0.75~0.85

    1.0~1.2

    1.1~1.4

    1.2~1.8

    1.2~1.8

    1.2~1.8

    1.2~1.8

    1.2~1.8

    1.2~1.8

    12


    0.6~0.7

    0.9~1.0

    0.9~1.2

    1.0~1.5

    1.0~1.5

    1.0~1.5

    1.0~1.5

    1.0~1.5

    1.0~1.5

    16




    0.6~0.75

    0.7~0.85

    0.7~0.85

    0.7~0.85

    0.7~0.85

    0.7~0.85

    0.7~0.85

    20





    0.6~0.75

    0.6~0.75

    0.6~0.75

    0.6~0.75

    0.6~0.75

    0.6~0.75

    22





    0.5~0.65

    0.5~0.65

    0.5~0.65

    0.5~0.65

    0.5~0.65

    0.5~0.65

    25





    0.4~0.6

    0.4~0.6

    0.4~0.6

    0.4~0.6

    0.4~0.6

    0.4~0.6



    Material

    Thickness

    mm

    500W

    1000W

    1500W

    2000W

    3000W

    4000W

    6000W

    8000W

    10000W

    12000W

    Cutting   Speed(m/min)

    Stainless Steel

    (N2)

    1

    10~12

    15~18

    10~15

    35~50

    45~55

    45~55

    45~55

    45~55

    45~55

    45~55

    2

    2~4.0

    4.5~6.0

    5.0~7.0

    10~15

    15~23

    18~27

    20~35

    23~37

    26~40

    28~43

    3

    0.7~2.0

    2.0~2.4

    3.0~4.0

    5.0~7.0

    7.0~11.0

    10~15

    15~20

    19~24

    23~28

    27~32

    4


    1.0~1.5

    2.0~2.8

    3.5~4.5

    4.0~6.0

    5.0~7.5

    10~14

    14~17

    18~22

    22~26

    5


    0.75~0.85

    1.2~1.7

    1.8~2.5

    2.5~4.0

    4.0~5.0

    8.0~12.0

    11~14

    14~17

    16~18

    6



    0.7~1.0

    0.7~0.8

    2.0~3.2

    3.0~4.0

    6.0~8.0

    8.0~9.5

    9.5~11.0

    10.5~12.0

    8



    0.5~0.7

    0.5~0.6

    1.2~1.8

    1.5~2.6

    3.5~4.0

    5.0~5.5

    6.5~7.0

    7.5~8.0

    10





    0.7~0.9

    0.7~1.3

    1.8~2.2

    2.5~3.0

    3.4~3.9

    4.0~4.5

    12





    0.3~0.4

    0.4~0.6

    1.2~1.5

    1.8~2.1

    2.6~3.1

    3.3~3.6

    16






    0.3~0.5

    0.8~1.2

    1.5~1.8

    2.2~2.5

    2.7~3.0

    20






    0.3~0.5

    0.6~0.8

    1.0~1.3

    1.7~2.0

    2.2~2.5

    22







    0.3~0.4

    0.6~0.75

    1.0~1.2

    1.4~1.6

    25








    0.3~0.5

    0.4~0.6

    0.6~0.8



    Material

    Thickness

    mm

    500W

    1000W

    1500W

    2000W

    3000W

    4000W

    6000W

    8000W

    10000W

    12000W

    Cutting   Speed(m/min)

    Aluminum (N2)

    1



    10~15

    30~45

    30~38

    35~40

    45~55

    45~55

    45~55

    45~55

    2



    5.0~6.0

    10~15

    12~16

    13~22

    20~30

    27~35

    33~40

    36~43

    3



    2.5~3.5

    5.0~7.0

    6.5~8.0

    7.0~13

    13~18

    15~18

    18~22

    23~26

    4



    1.4~2.0

    3.5~5.0

    3.5~5.0

    4.0~5.5

    10~12

    12~13.5

    15~18

    19~22

    5



    0.8~1.0

    2.0~3.0

    2.5~3.5

    3.4~4.0

    5.0~8.0

    9.0~12

    14~16

    17~19

    6



    0.5~0.6

    1.5~2.0

    1.8~3.0

    2.2~3.5

    4.0~6.0

    7.5~9.5

    10~12.5

    13~15

    8




    0.5~0.6

    0.9~1.3

    0.9~1.6

    2.0~3.0

    4.0~4.8

    5.8~6.5

    6.8~7.2

    10





    0.4~0.7

    0.55~1.0

    1.0~1.9

    1.5~2.7

    3.0~3.8

    3.7~4.2

    12





    0.3~0.45

    0.4~0.6

    0.8~1.4

    1.6~1.9

    2.4~2.7

    3.3~3.6

    16






    0.3~0.4

    0.6~0.9

    1.0~1.2

    1.4~1.6

    1.7~1.8

    20







    0.4~0.6

    0.8~0.9

    1.0~1.2

    1.2~1.6

    22








    0.7~0.85

    0.9~1.0

    1.1~1.2

    25








    0.35~0.45

    0.6~0.7

    0.8~0.9



    Material

    Thickness

    mm

    500W

    1000W

    1500W

    2000W

    3000W

    4000W

    6000W

    8000W

    10000W

    12000W

    Cutting   Speed(m/min)

    Brass (N2)

    1



    8.0~12

    12~18

    20~32

    25~30

    45~55

    45~55

    45~55

    45~55

    2



    3.5~5.0

    6.0~8.5

    9.0~11

    10~13

    25~35

    27~35

    33~40

    36~43

    3



    1.5~2.2

    2.5~4.0

    4.0~6.0

    5.0~6.5

    12~18

    15~18

    18~22

    23~26

    4



    1.0~1.2

    1.5~1.8

    3.0~4.5

    3.0~5.2

    8.0~10

    12~13.5

    15~18

    19~22

    5



    0.6~0.8

    0.8~1.2

    1.5~2.0

    2.0~3.0

    4.5~6.0

    9.0~12

    14~16

    17~19

    6




    0.4~0.5

    1.0~1.6

    1.4~2.0

    3.0~4.0

    7.5~9.5

    10~12.5

    13~15

    8





    0.5~0.6

    0.7~0.8

    1.6~2.2

    4.0~4.8

    5.8~6.5

    6.8~7.2

    10






    0.2~0.3

    0.8~1.2

    1.5~2.7

    3.0~3.8

    3.7~4.2

    12








    1.6~1.9

    2.4~2.7

    3.3~3.6





    Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 31 COMPANY PROFILE Exchange table fiber optic tube cutter fiber tube cutter fiber laser tube cutting 32

    Jinan Lingxiu Laser

    Is established in July 2004 owns more than 500 square meters of researching and office space, more than 32000 square meters factory All machines, passed the European Union CE authentication American FDA cerificate and are certied to ISO 9001. Products are sold to USA, Canada, Australia, Europe. South east Asia, Afica etc, more than 120 counties and areas, and supply OEM service for more than 30 manufactures.


    Our Products includes All kind of

    1.Fiber laser cutting machine/Laser marking/welding/CO2 laser engraving/cleaning machine. 2.Vibrating knife cutting machine.

    We can also customized non-standard assist equipment as your detailed work reauirements.
