Model | SS-UV |
Laser Type/Wavelength | ND:Yvo4/355nm |
Laser Source | Semiconductor 808nm Diode pump |
Max Power | 2W/3W/5W |
Laser Beam Characteristics | 1.1 |
Repetition Frequency | 0-90KHZ |
Mini Marking Character | 0.1mm |
Mini Marking Line | 0.01mm |
Marking Speed | ≤3500 charecter/s |
Repeat Precision | 0.001mm |
Marking Area | 110×110mm(optional) |
Measurement | 900×680×1200mm |
Net Weight | 120kg |
Power Supply | 220V/50hz/10A |
Cooling Method | water cooling |
Gross Power | ≤1200W |
Equipment description:
Ultraviolet (UV) laser is a kind of cold light, mainly used in super precise marking and engraving , particularly
suitable for food , pharmaceutical packaging material marking , micro punching, glass high-speed dividing , silicon
wafer complex graphics cutting, etc.
Without heat effect , the effect of laser marking and cutting is precise , smooth and steep. Except copper, 355nm
UV laser could be absorbed by many materials , so it is suitable for manufacture more material type.
1, Equpped with high end UV laser generator
2,Utra light scanning gavanometer system.
3,Small focusing light spot, excellent quality of output beam, reliable.
4,Low consuming inf energy, green materials , maintenance free.
5,Imported optical system.
6,Ergonomic interface and surface design , small and exquisite.
7,Special UV controlling software, strong compatibility, enable to achieve high speed, high precision,
extending the time of operation .
Applicable industries:
Electronic communication , electrical and electronic, instrumintation, hardware, mobile devices,
ceramics and other industries.
Applicable Materials
Transparent polymer materials,electronic components reflection film,plastic buttons,wire harmess
glass,ceramics ans potteries,tiles, aluminum nameplates. metallic and non-metallic materials,etc.
SAMPLES
