1 Model Number: LXC- 100W
2 Lead time: 10-25 working days
3 Payment Term:T/T: Alibaba trade assurance;West Union;Paypal;L/C.
4 Machine Size: 700*580*400mm
5 Machine weight: 47KG
6 Brand: LXSHOW
7 Warranty: 2 years
8 Shipping: By sea/By air/By Railway
PRODUCT PARAMETER
Laser Type |
LXC-100W |
Wavelength(nm) |
1060-1085 |
Nominal Average Output Power(W) |
≥100W |
Single Pulse Energy(mJ) |
1.25@80kHZ |
Beam Diameter(mm) |
5.5-8 |
Pulse Duration(ns) |
205-290@80kHZ |
Output Power Tunability(%) |
10-100 |
Cooling Method |
Air Cooled |
Power Supply Voltage |
48V |
Power Consumption |
<400W |
Power supply current requirement |
>8A |
Central Wavelength |
1064nm |
Emission Bandwidth (FWHM)@3dB |
<15nm |
Polarization |
Random |
Anti-Reflection Protection |
Yes |
Output Beam Diameter |
4.0±0.5mm,7.5±0.5mm(Customizable) |
Output Power Tuning Range |
0~100% |
Ambient Temperature Range |
0~40℃ |
Storage Temperature Range |
-10~60℃ |
Dimensions |
700*5800*400mm |
Weight |
28 Kg |
COMPANY PROFILE
Jinan Lingxiu Laser
Is established in July 2004 owns more than 500 square meters of researching and office space, more than 32000 square meters factory All machines, passed the European Union CE authentication American FDA cerificate and are certied to ISO 9001. Products are sold to USA, Canada, Australia, Europe. South east Asia, Afica etc, more than 120 counties and areas, and supply OEM service for more than 30 manufactures.
Our Products includes All kind of
1.Laser Cleaning machine
2.Laser marking/welding machine(Fiber/CO2/UV/Green light)/Fiber laser cutting machine
3.Vibrating knife cutting cnc machine
We can also customized non-standard assist equipment as your detailed work reauirements.
